Schneider A9K24216 | Miniature circuit-breaker, Acti9 iK60N, 2P, 16 A, C curve, 6000 A (IEC 60898-1)
Out of stock
Schneider A9K24216
726 EGP 1,008 EGP
Out of stock
CompareSchneider A9K24216
Schneider A9K24216
Introduction
Circuit breakers are crucial components in electrical systems, safeguarding against overloads and short circuits. Among the various models available, it stands out for its exceptional features and reliability. In this article, we’ll delve into everything you need to know about the Schneider A9K24216, from its benefits and applications to installation and maintenance tips.
What is the Schneider A9K24216?
it is a high-quality circuit breaker designed for a wide range of applications. Known for its robustness and reliability, this model offers excellent protection against electrical faults. It boasts a compact design, making it suitable for both small and large installations.
Key Features and Specifications
- Rated Current: 16A
- Rated Voltage: 240V
- Breaking Capacity: 6kA
- Poles: 2P (Double Pole)
- Type: Acti 9 Series
- Compliance: IEC 60898-1 standards
These features ensure that it provides efficient and reliable performance, catering to various electrical needs.
Benefits of Using Schneider A9K24216
Safety Enhancements
Safety is paramount when dealing with electrical systems, and the Schneider A9K24216 excels in this area. It is designed to quickly interrupt the current flow in case of overloads or short circuits, preventing potential hazards.
Reliability and Durability
Built with high-quality materials, this circuit breaker promises long-lasting performance. Its robust construction ensures that it can withstand harsh conditions and frequent use without compromising functionality.
Energy Efficiency
it is engineered to minimize energy loss, contributing to overall energy efficiency in your electrical system. This not only helps in reducing electricity bills but also promotes environmental sustainability.
Applications of Schneider A9K24216
Residential Usage
In homes, it provides reliable protection for household electrical circuits, safeguarding appliances and preventing electrical fires.
Commercial Usage
For businesses, this circuit breaker ensures the smooth operation of electrical systems, protecting critical equipment and reducing downtime due to electrical issues.
Industrial Usage
In industrial settings, it is essential for protecting heavy machinery and complex electrical setups, ensuring continuous and safe operations.
Technical Specifications
Electrical Ratings
- Rated Frequency: 50/60 Hz
- Insulation Voltage: 500V
- Operating Temperature: -5°C to +40°C
Physical Dimensions
- Height: 85mm
- Width: 35mm
- Depth: 78mm
- Weight: 200g
Compliance and Standards
it complies with international standards such as IEC 60898-1, ensuring it meets rigorous safety and performance criteria.
Installation Process
Pre-Installation Checks
Before installing it, ensure that the power supply is turned off and that you have all necessary tools and materials.
Step-by-Step Installation Guide
- Turn Off Power: Ensure the main power supply is switched off.
- Mount the Breaker: Securely mount the breaker in the distribution board.
- Connect Wires: Connect the input and output wires to the breaker terminals.
- Secure Connections: Tighten all connections to ensure there are no loose wires.
- Test the Installation: Turn on the power and test the breaker to ensure it operates correctly.
Post-Installation Testing
After installation, conduct thorough testing to confirm that the breaker functions properly under normal and fault conditions.
Comparing Schneider A9K24216 with Other Models
The A9K24216 and A9K24210 are similar in many respects but differ mainly in their rated current and breaking capacity. The A9K24216 offers a higher rated current and breaking capacity, making it suitable for more demanding applications.
Schneider A9K24216 vs. Competitors
Compared to competitors, the Schneider A9K24216 stands out due to its superior build quality, higher breaking capacity, and compliance with stringent safety standards.
Maintenance Tips
Routine Inspections
Regularly inspect the breaker for any signs of wear or damage. Ensure that connections are tight and that there are no signs of overheating.
Troubleshooting Common Issues
If the breaker trips frequently, check for overloaded circuits or short circuits. Ensure that the breaker is not being subjected to conditions beyond its rated capacity.
When to Replace
Replace the breaker if it shows signs of significant wear, damage, or if it fails to operate correctly during testing.
Safety Tips for Handling Circuit Breakers
Precautions During Installation
Always turn off the main power supply before installing or servicing the circuit breaker. Use insulated tools and wear protective gear.
Safety During Maintenance
Regularly test the breaker to ensure it functions correctly. If any issues are found, address them immediately to prevent potential hazards.
| Device application | Distribution |
|---|---|
| Range | Acti9 |
| Product name | Acti9 iK60 |
| product or component type | Miniature circuit-breaker |
| Device short name | iK60N |
| Poles description | 2P |
| Number of protected poles | 2 |
| [In] rated current | 16 A at 30 °C |
| Network type | AC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 6000 A Icn at 230 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| Suitability for isolation | Yes conforming to EN/IEC 60898-1 |
| Standards | EN/IEC 60898-1 |
| Network frequency | 50/60 Hz |
|---|---|
| Magnetic tripping limit | 5…10 x In |
| [Ics] rated service breaking capacity | 6000 A 100 % conforming to EN/IEC 60898-1 – 230 V AC 50/60 Hz |
| Limitation class | 3 conforming to EN/IEC 60898-1 |
| [Ui] rated insulation voltage | 440 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| [Uimp] rated impulse withstand voltage | 4 kV conforming to EN/IEC 60898-1 |
| Contact position indicator | No |
| Control type | Toggle |
| Local signalling | ON/OFF indication |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| 9 mm pitches | 4 |
| Height | 85 mm |
| Width | 36 mm |
| Depth | 78.5 mm |
| net weight | 200 g |
| Colour | White |
| Mechanical durability | 20000 cycles |
| Electrical durability | 10000 cycles |
| Locking options description | Padlocking device |
| Connections – terminals | Tunnel type terminal (top or bottom) 1…25 mm² rigid Tunnel type terminal (top or bottom) 1…16 mm² flexible |
| Wire stripping length | 14 mm for top or bottom connection |
| Tightening torque | 2 N.m top or bottom |
| earth-leakage protection | Without |
| IP degree of protection | IP20 conforming to IEC 60529 |
|---|---|
| Pollution degree | 2 conforming to EN/IEC 60898-1 |
| Overvoltage category | II |
| Ambient air temperature for operation | -25…60 °C |
| ambient air temperature for storage | -40…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.500 cm |
| Package 1 Width | 7.500 cm |
| Package 1 Length | 9.500 cm |
| Package 1 Weight | 192.000 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 6 |
| Package 2 Height | 8.500 cm |
| Package 2 Width | 10.000 cm |
| Package 2 Length | 22.000 cm |
| Package 2 Weight | 1.212 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 66 |
| Package 3 Height | 30.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 13.846 kg |
| Warranty | 18 months |
|---|
