Schneider A9N61501 | miniature circuit breaker – C60H – 1 pole – 1 A – C curve

Schneider A9N61501 | miniature circuit breaker – C60H – 1 pole – 1 A – C curve

Technical Specifications A9N61501

• Product Reference: A9N61501

• Series: Acti9 C60H

• Device Type: Miniature Circuit Breaker (MCB)

• Number of Poles: 1P (Single Pole)

• Rated Current (In): 1 A

• Tripping Curve: C Curve – trips between 5 to 10 times the rated current

• Breaking Capacity:

  • Up to 6000 A (depending on standard and installation context)

• Rated Voltage: 230/400 V AC

• Frequency: 50/60 Hz

• Installation: DIN rail mount

• Terminal Capacity: Tunnel terminals for copper cables

• Standards Compliance:

  • IEC/EN 60898-1

  • IEC/EN 60947-2

Key Features:

• Precise Protection at Low Current
  Rated at just 1 A, it’s ideal for fine protection of sensitive control or signal lines.

• C Curve Tripping
  Suitable for general-purpose loads with moderate inrush currents, such as small motors, lights, or electronic devices.

• High-Quality Construction
  Engineered by Schneider Electric for durability and long service life.

• Compact Modular Design
  Saves space in distribution panels, easily integrates into modular electrical systems.

• Safe and Easy Installation
  Clip-on mounting to DIN rails with secure, screw-type terminals.

• Global Standards Compliance
  Approved for use worldwide in accordance with leading safety standards.

Applications:

• Control and Automation Panels
  Protects low-current signal lines and control circuits in industrial systems.

• Lighting Circuits
  Suitable for LED or fluorescent lighting where circuit protection at low amperage is required.

• Residential Sub-Distribution Boards
  Provides precise protection for specialty circuits such as doorbells, thermostats, or alarm systems.

• Commercial Installations
  Ideal for office equipment or low-load circuits requiring reliable fault protection.

• Industrial Environments
  Used in instrumentation systems or protection of electronic sensors.
