Schneider A9N61506 | miniature circuit breaker – C60H – 1 pole – 6 A – C curve

 Schneider A9N61506 | miniature circuit breaker – C60H – 1 pole – 6 A – C curve

Technical Specifications A9N61506

• Product Reference: A9N61506

• Series: Acti9 C60H

• Type: Miniature Circuit Breaker (MCB)

• Number of Poles: 1P (Single Pole)

• Rated Current (In): 6 A

• Tripping Curve: C Curve (trips at 5–10 × rated current)

• Breaking Capacity: Up to 6 kA (as per IEC/EN 60898-1)

• Rated Operational Voltage: 230/400 V AC

• Frequency: 50/60 Hz

• Mounting Method: DIN rail (modular installation)

• Terminal Type: Screw terminals, top and bottom

• Protection Degree: IP20 (when enclosed)

• Conformity Standards:

  • IEC/EN 60898-1

  • IEC/EN 60947-2

Key Features:

• Reliable 6 A Circuit Protection
  Ideal for small circuits, lighting systems, or auxiliary loads.

• C Curve Performance
  Offers protection against both overloads and short circuits, while tolerating temporary inrush currents.

• Compact and Modular
  Saves panel space and integrates easily with other modular components.

• Easy to Install
  Clip-on DIN rail mounting with secure terminal connections.

• Durable and High Quality
  Engineered by Schneider Electric for long-lasting performance and safety.

• Global Certification
  Suitable for international installations thanks to full compliance with major standards.

Applications:

• Residential Lighting Circuits
  Provides protection for home lighting or small appliance circuits.

• Commercial Panel Boards
  Protects control loops, emergency lighting, or backup circuits.

• Industrial Control Panels
  Ensures safety of instrumentation and control devices.

• Automation Systems
  Ideal for protecting PLC inputs, sensors, and relays.

• Data Centers and IT Installations
  Protects low-load circuits where precision and reliability are critical.
