Schneider ABL2REM24015K Modicon

Schneider ABL2REM24015K Modicon | Single phase power supply, 100…240V input, 24V DC output, 36W, 1,5A

Schneider Electric
Availability:

Out of stock

Schneider ABL2REM24015K Modicon

853.91 EGP 1,805.30 EGP

Out of stock

Schneider ABL2REM24015K Modicon | Single-Phase Power Supply – 100-240V Input, 24V DC Output, 36W, 1.5A

1. Overview

The Schneider ABL2REM24015K is a single-phase power supply from the Modicon ABL2REM series, designed to convert 100-240V AC input into a stable 24V DC output. With a 36W power rating and 1.5A output current, this compact and reliable power supply is ideal for industrial automation, PLC systems, and control panels.

2. Key Features

  • Model: ABL2REM24015K
  • Series: Modicon ABL2REM
  • Input Voltage Range: 100-240V AC
  • Output Voltage: 24V DC
  • Output Current: 1.5A
  • Power Rating: 36W
  • Mounting Type: DIN rail or panel mounting
  • Compact & Lightweight: Space-saving design for easy installation
  • Protection Features: Overload, short-circuit, overvoltage protection

3. Technical Specifications

  • Input Frequency: 50/60Hz
  • Efficiency: ≥85% (high energy efficiency)
  • Ripple & Noise: ≤100mV (ensures stable DC output)
  • Operating Temperature: -10°C to +70°C
  • Protection Rating: IP20 (for panel installation)
  • Connection Type: Screw terminals for secure wiring
  • Certifications & Compliance: CE, UL, RoHS compliant

4. Applications

  • PLC and Industrial Automation Systems
  • Control Panels & Electrical Cabinets
  • Sensors, Relays, and Low-Power DC Devices
  • Building Management Systems (BMS)
  • LED Lighting & Signaling Equipment

5. Benefits

  • Reliable Power Conversion: Ensures stable 24V DC output for sensitive equipment
  • Energy Efficient: High efficiency reduces energy waste
  • Compact Design: Ideal for space-constrained control panels
  • Built-in Protections: Protects against short circuits, overvoltage, and overloads
  • Easy Integration: Compatible with Schneider Modicon PLCs and automation systems

6. Conclusion

The Schneider ABL2REM24015K Modicon is a high-quality, compact power supply designed for reliable 24V DC power delivery in industrial and automation applications. With its robust protection features, high efficiency, and compact design, it is an excellent choice for control panels and PLC-based systems.

SKU: ABL2REM24015K Category: Tags: , , , , , Brand:
Main
Range of product Easy Modicon ABL2
Product or component type Power supply
Power supply type Regulated switch mode
Rated power in W 36 W
Main Input Voltage 100…240 V AC single phase
Output voltage 24 V DC
Power supply output current 1.5 A
Operating position Any position
Vibration resistance 4 gn (f= 10…500 Hz) conforming to IEC 61131-2
Name of test Electromagnetic hypersensitivity (EHS) conforming to IEC 61000-6-2 level A
Complementary
Input voltage limits 85…264 V
Network frequency 47…63 Hz
Inrush current 45 A at 100…240 V AC
Cos phi 0.45
Efficiency 87 %
Power dissipation in W 5.4 W
Current consumption 0.4 A at 240 V
Input protection type Integrated fuse (not interchangeable)
Output voltage limits 20.4…27.6 V
Line and load regulation +/- 1 %
Holding time >= 12 ms at 115 V
Output protection type Against overload, protection technology: 1.1…1.5 x In
Against short-circuits, protection technology: 1.1…1.5 x In
Against overvoltage, protection technology: 28.8…33.6 V
Connections – terminals For ground connection: screw type terminals, connection capacity: 1 x 4 mm² AWG 12
Marking CE
Electromagnetic compatibility Immunity to electromagnetic interference conforming to EN 55022 class B
Mounting support DIN rail with accessory
Panel mounting with accessory
Operating altitude 5000 m
Output coupling Series
Overvoltage category II
Meantime between failure [MTBF] 600000 h at 25 °C
Status LED 1 LED (green) output voltage
Width 99 mm
Height 82 mm
Depth 30 mm
Net weight 0.23 kg
Environment
Product certifications EAC
IC
RoHS
KC
RCM
IP degree of protection IP20 conforming to IEC 62368-1
Ambient air temperature for operation -30…70 °C (with power derating of 2.5 % per °C)
Ambient air temperature for storage -40…85 °C
Relative humidity 10…95 %
Overvoltage category Class I conforming to IEC 62368-1
Pollution degree 2
Dielectric strength 2000 V between input and ground
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 3.744 cm
Package 1 Width 8.79 cm
Package 1 Length 10.549 cm
Package 1 Weight 231.0 g
Unit Type of Package 2 S03
Number of Units in Package 2 63
Package 2 Height 30.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2 Weight 15.19 kg
