Schneider CCT15369 | Acti 9 IC2000 outdoor (2 – 2000 lux) twilight switch
Availability:
In stock
Schneider CCT15369 | Acti 9 IC2000 outdoor (2 – 2000 lux) twilight switch
5,182.16 EGP 8,291.45 EGP
In stock
CompareSchneider CCT15369 | Acti 9 IC2000 outdoor (2 – 2000 lux) twilight switch
Technical Specifications
The CCT15369 twilight switch operates in a light-sensing range between 2 and 2000 lux, allowing precise adjustment based on lighting needs. It is suitable for outdoor installation and built to withstand environmental exposure. The unit works with a 230 V AC power supply and supports DIN rail mounting for easy integration into electrical distribution panels. It typically has a switching capacity of up to 16 A resistive load, making it suitable for both small and large lighting installations. The sensor is external and weather-resistant, connected to the control unit for accurate light detection.
Key Features
The Schneider CCT15369 features an adjustable lux threshold that allows users to determine the exact ambient light level at which the lights should be turned on or off. It is equipped with high-quality electronics for reliable performance over time, and it responds quickly to changing light conditions without false triggering due to temporary light fluctuations.
This device is specially designed for outdoor use, with durable housing that offers protection against dust and moisture. The product includes an external sensor that can be mounted separately from the control unit, ensuring optimal placement for accurate light measurement.
The twilight switch contributes to energy savings by reducing unnecessary lighting during daylight hours, and enhances safety and security by automatically turning on lights at dusk and off at dawn.
Applications
The CCT15369 is commonly used in street lighting systems, where it automatically activates the lights at sunset and deactivates them at sunrise. It is also ideal for garden lighting, public parks, building façades, parking areas, and industrial yards, where consistent and automatic lighting control is required. In residential settings, it can be used for entrance lighting or driveways, providing hands-free lighting operation based on natural light levels.
| range of product | Acti9 |
|---|---|
| Product name | Acti9 IC |
| product or component type | Twilight switch |
| Device short name | IC2000 |
| Provided equipment | Twilight sensor outdoor |
| Load type | Incandescent lamp: 2600 W halogen lamp: 2600 W non-corrected fluorescent tube: 2300 VA serial-compensated fluorescent tube: 2300 VA parallel compensated fluorescent lamp: 730 VA (80 µF) compact fluorescent lamp: 170 W < 2 W LED lamp: 30 W > 2 W LED lamp: 200 W |
| Device application | Building |
|---|---|
| Number of channels | 1 |
| Maximum power consumption in W | 0.5 W stand by |
| [Ue] rated operational voltage | 230 V AC +10 % -15 % at 50/60 Hz |
| Maximum switching current | 10 A – 250 V AC pf = 0.6 16 A – 250 V AC pf = 1 |
| Minimum switching current | 10 mA 230 V AC 100 mA 24 V AC/DC |
| Electrical insulation class | Class II |
| Output type | Dry contact |
| Accuracy | +/- 0.25 s/day 25 °C |
| Contacts type and composition | 1 NO |
| Time delay | 20 s on 80 s off |
| Light intensity adjustment | 2…2000 lux |
| Connections – terminals | 1 x 2.5 mm² screw terminals solid or flexible with sleeve 2 x 0.5…2.5 mm² screw terminals solid or flexible |
| Mounting support | TH35 DIN rail conforming to EN 60715 |
| Height | 85.5 mm |
| Width | 18 mm |
| Depth | 67 mm |
| net weight | 111 g |
| Overvoltage category | Class 3 |
| marking | CE |
| Control type | By brightness detection |
| Ambient air temperature for operation | -30…55 °C |
|---|---|
| ambient air temp for storage/transportation | -30…70 °C |
| Relative humidity | 90 %, non-condensing |
| IP degree of protection | IP20 IP55 (sensor) |
| Standards | EN 60669-2-1 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 6.5 cm |
| Package 1 Width | 8.0 cm |
| Package 1 Length | 10.5 cm |
| Package 1 Weight | 161.0 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 40 |
| Package 2 Height | 30 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 6.89 kg |
| Package 3 Height | 80 cm |
Main Document
Data Sheet : CCT15369
