Schneider GM63D4N6304BEE | GoMTS 630 Amps – Extended Rotary Handle – 4 Poles – 415 V
In stock
33,201 EGP 45,481 EGP
In stock
CompareSchneider GM63D4N6304BEE | GoMTS 630 Amps – Extended Rotary Handle – 4 Poles – 415 V
Manual transfer switch, GoPact MTS 630, 4 poles, 630A, 415VAC 50/60Hz, extended rotary handle, open transition
Schneider GM63D4N6304BEE: Comprehensive Product Overview
Motor protection is a crucial factor in maintaining the efficiency and longevity of industrial equipment. The Schneider GM63D4N6304BEE motor circuit breaker offers advanced protection that ensures reliable operation in high-demand settings. With this breaker, businesses can safeguard their motors from electrical faults, reducing the risk of costly downtime and damage to equipment.
About Schneider Electric
Schneider Electric is a global leader in energy management and automation, providing cutting-edge electrical solutions for businesses of all sizes. With a history of innovation, the company has developed a wide range of motor circuit breakers designed to protect electrical systems, including the GM63D4N6304BEE model, known for its advanced features and high reliability.
Decoding the GM63D4N6304BEE Model Code
The GM63D4N6304BEE is a motor circuit breaker, and its model code provides key insights into its specifications:
- GM refers to the General Motor application.
- 63D4 identifies the model series and design features.
- N6304 indicates the rated voltage and current capacity, helping users determine its suitability for different applications.
- BEE typically relates to certifications and additional features, ensuring compliance with industrial standards.
How Motor Circuit Breakers Work
Motor circuit breakers like the Schneider GM63D4N6304BEE are designed to protect electric motors from overloads and short circuits. When electrical faults are detected, the breaker automatically interrupts the power flow, preventing damage to the motor and associated equipment. This mechanism is vital in industrial settings where electrical equipment is subject to heavy loads and continuous operation.
Key Features of Schneider GM63D4N6304BEE
1. Overload and Short Circuit Protection
The GM63D4N6304BEE offers robust protection against overloads and short circuits, ensuring that motors operate safely under fluctuating electrical conditions. The breaker trips automatically when electrical faults occur, minimizing the risk of damage.
| brands | Schneider Electric |
|---|
| Range of product | GoPact MTS |
|---|---|
| Product or component type | Manual transfer switch |
| Product name | GoPact MTS 630 |
| Device application | Change source of supply |
| frame size | 630 |
| Suitability for isolation | Yes conforming to IEC 60947-3 |
| transfer switch class | PC |
| poles description | 4P |
| [Ie] rated operational current | AC-21A: 630 A conforming to IEC 60947-3 AC-22A: 630 A conforming to IEC 60947-3 AC-23A: 630 A conforming to IEC 60947-3 AC-31B: 630 A conforming to IEC 60947-6-1 AC-32B: 630 A conforming to IEC 60947-6-1 |
| [Ith] conventional free air thermal current | 630 A at 40 °C |
| [Ithe] conventional enclosed thermal current | 630 A (40 °C) |
| Rated operational power in W | 315 kW AC-23A conforming to IEC 60947-3 |
| [Ue] rated operational voltage | 415 V AC 50/60 Hz |
| Breaking capacity | 5040 A AC-23A |
| Rated making capacity | 6300 A AC-23A |
| Control type | Extended rotary handle |
| Operating mode | Manual |
| Contact position indicator | Yes |
| mechanical interlocking | With mechanical interlocking |
| Locking options description | Padlocking in OFF position 1 to 3 padlocks |
| [Ui] rated insulation voltage | 1000 V AC |
|---|---|
| [Uimp] rated impulse withstand voltage | 12 kV |
| [Icm] rated short-circuit making capacity | 46.2 kA peak |
| [Icw] rated short-time withstand current | 22 kA during 1 s conforming to IEC 60947-4-3 35 kA during 0.2 s conforming to IEC 60947-4-3 22 kA during 0.1 s conforming to IEC 60947-6-1 |
| Number of contact position | 3 |
| mounting mode | Fixed |
| Mounting support | Backplate |
| Connections – terminals | 2 cable with lug wire size 300 mm² |
| Tightening torque | 27 N.m |
| Mechanical durability | 10000 cycles |
| Electrical durability | 1000 cycles 415 V |
| Width | 310 mm |
| Height | 329 mm |
| Depth | Without handle : 210 mm With handle : 316 mm |
| Net weight | 14.5 kg |
| Standards | IEC 60947-3 IEC 60947-6-1 |
| product certifications | IECEE CB Scheme |
| Electrical shock protection class | Class II |
|---|---|
| IP degree of protection | IP54 front face conforming to IEC 60529 |
| Pollution degree | 3 conforming to IEC 60664-1 |
| Ambient air temperature for operation | -5…55 °C |
| Temperature derating table | 40 °C ( 630 A ) 45 °C ( 630 A ) 50 °C ( 630 A ) 55 °C ( 598 A ) |
| Ambient air temperature for storage | -25…85 °C |
| Operating altitude | 2000 m 100 % of In 3000 m 96 % of In 4000 m 93 % of In 5000 m 89 % of In |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 37.5 cm |
| Package 1 Width | 34.5 cm |
| Package 1 Length | 39.5 cm |
| Package 1 Weight | 20.2 kg |
| Unit Type of Package 2 | P06 |
| Number of Units in Package 2 | 2 |
| Package 2 Height | 88.4 cm |
| Package 2 Width | 60 cm |
| Package 2 Length | 80 cm |
| Package 2 Weight | 89.6 kg |
