Schneider GZ1E22 | Motor circuit breaker, EasyPact, TVS GZ1E, AC-3, 3P, 20..25A, thermal magnetic detection
Out of stock
1,533 EGP 2,838 EGP
Out of stock
CompareSchneider GZ1E22 | Motor circuit breaker, EasyPact, TVS GZ1E, AC-3, 3P, 20..25A, thermal magnetic detection
Schneider GZ1E22 Motor Circuit Breaker: Enhancing Industrial Safety and Efficiency
In today’s dynamic industrial landscape, ensuring the safety and efficiency of electrical systems is paramount. Schneider Electric’s GZ1E22 motor circuit breaker stands out as a reliable solution designed to protect motors and circuits while optimizing performance. Let’s delve into the features and benefits of this innovative product.
Introduction to Schneider GZ1E22 Motor Circuit Breaker
A motor circuit breaker serves as a crucial component in electrical systems, providing protection against overloads, short circuits, and phase failures. Schneider Electric, a leader in energy management and automation, introduces the GZ1E22 model, known for its robustness and performance.
EasyPact Technology in GZ1E22
One of the standout features of GZ1E22 is its integration with EasyPact technology. This advanced technology enhances the breaker’s reliability, simplifies installation, and reduces downtime, contributing to overall operational efficiency.
TVS GZ1E: Features and Specifications
The TVS GZ1E component within this breaker further enhances its functionality. With a focus on AC-3 ratings and 3-phase operations, it ensures seamless performance in demanding industrial environments.
AC-3 Rating and Its Significance
The AC-3 rating in GZ1E22 signifies its capability to handle motor loads, making it suitable for heavy-duty applications. This rating is a crucial parameter for industries requiring reliable circuit protection.
Thermal Magnetic Detection in GZ1E22
Thermal magnetic detection is a key feature that enables quick and accurate response to overcurrents and short circuits. This proactive protection mechanism minimizes downtime and safeguards equipment.
Application Range: 3P, 20-25A
The GZ1E22 model is optimized for 3-phase systems with a current range of 20-25A, making it versatile for various industrial setups. Its adaptability and performance make it a preferred choice for engineers and operators.
Installation and Maintenance Guidelines
Proper installation and regular maintenance are essential for maximizing the lifespan of GZ1E22. Following Schneider Electric’s guidelines ensures safe and reliable operation, reducing the risk of unexpected failures.
Comparison with Other Models
When compared to similar models, GZ1E22 showcases superior performance, enhanced features, and a proven track record in demanding environments. Its robust construction and technological advancements set it apart in the market.
Real-World Use Cases
Numerous industries, from manufacturing to infrastructure, rely on GZ1E22 for critical electrical protection. Real-world examples highlight its effectiveness in ensuring uninterrupted operations and preventing costly downtime.
Future Developments and Upgrades
Schneider Electric remains committed to innovation and continuous improvement. Future upgrades and developments in the GZ1E22 series aim to address evolving industry needs, further solidifying its position as a leading motor circuit breaker.
Conclusion
In conclusion, the Schneider GZ1E22 motor circuit breaker represents a blend of cutting-edge technology and robust engineering, delivering unparalleled safety and efficiency in industrial settings. Its advanced features, coupled with Schneider Electric’s reputation for quality, make it a trusted choice for engineers and facility managers worldwide.
| Range | Easy TeSys |
|---|---|
| range of product | Easy TeSys Power |
| product or component type | Circuit breaker |
| Device short name | GZ1E |
| device application | Motor |
| Trip unit technology | Thermal-magnetic |
| Suitability for isolation | Yes conforming to IEC 60947-1 appendix 7.1.6 |
| Colour | Grey (RAL 7011) |
| Poles description | 3P |
|---|---|
| Network type | AC |
| Utilisation category | AC-3 |
| Network frequency | 50/60 Hz conforming to IEC 60947-2 |
| mounting mode | By screws By clips |
| mounting support | Rail |
| Mounting position | Any position |
| Motor power kW | 5.5 kW at 230 V AC 50/60 Hz 11 kW at 440 V AC 50/60 Hz 11 kW at 400 V AC 50/60 Hz 15 kW at 500 V AC 50/60 Hz 22 kW at 690 V AC 50/60 Hz |
| Breaking capacity | Icu: 2 kA at 690 V AC 50/60 Hz conforming to IEC 60947-2 Icu: 10 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Icu: 30 kA at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 Icu: 5 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 Icu: 3 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ics] rated service short-circuit breaking capacity | 100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 75 % at 690 V AC 50/60 Hz conforming to IEC 60947-2 50 % at 440 V AC 50/60 Hz conforming to IEC 60947-2 75 % at 500 V AC 50/60 Hz conforming to IEC 60947-2 40 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 |
| Control type | Push-button |
| Thermal protection adjustment range | 20…25 A |
| Magnetic tripping current | 327 A |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ui] rated insulation voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 |
| Power dissipation | 2.5 W (per pole) |
| Mechanical durability | 100000 cycles |
| Electrical durability | 100000 cycles for AC-3 |
| Maximum operating rate | 25 cyc/h |
| Connections – terminals | Screw clamp terminals 2 1…6 mm² – cable stiffness: solid Screw clamp terminals 2 1.5…6 mm² – cable stiffness: flexible without cable end Screw clamp terminals 2 1…4 mm² – cable stiffness: flexible with cable end |
| Height | 89 mm |
| Width | 44.5 mm |
| Depth | 78 mm |
| net weight | 0.26 kg |
| Standards | IEC 60947-4 IEC 60947-2 |
|---|---|
| Protective treatment | TH |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Ambient air temperature for operation | -20…60 °C |
| Ambient air temperature for storage | -40…80 °C |
| Fire resistance | 960 °C conforming to IEC 60695-2-1 |
| Operating altitude | 2000 m |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 8.4 cm |
| Package 1 Width | 4.7 cm |
| Package 1 Length | 9 cm |
| Package 1 Weight | 275 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 6.991 kg |
