Schneider LAEN40 | Auxiliary contact block, EasyPact TVS, 4NO

Schneider Electric
Availability:

In stock


363 EGP 672 EGP

In stock

Compare

Schneider LAEN40 | Auxiliary contact block, EasyPact TVS, 4NO

Schneider LAEN40 | Auxiliary contact block, EasyPact TVS, 4NO
Introduction

In this article, we delve into the features and benefits of the Schneider LAEN40 auxiliary contact block designed for EasyPact TVS circuit breakers, specifically focusing on its 4NO (4 Normally Open) configuration.

Schneider LAEN40

it auxiliary contact block is a crucial component in electrical installations, providing additional control and signaling capabilities to EasyPact TVS circuit breakers.

EasyPact TVS

EasyPact TVS is a range of compact and reliable circuit breakers manufactured by Schneider Electric, known for their performance and safety features.

Auxiliary Contact Block

The auxiliary contact block expands the functionality of the circuit breaker by offering extra contacts that can be used for various purposes such as signaling, interlocking, or remote control.

4NO Description

The “4NO” designation indicates that this specific auxiliary contact block has four Normally Open contacts, providing versatility in electrical control applications.

Benefits

  • Enhanced control capabilities
  • Improved safety features
  • Versatile applications
  • Easy integration with EasyPact TVS breakers

Applications

it auxiliary contact block finds applications in various industries and settings, including:

  • Industrial automation
  • Building management systems
  • Renewable energy installations

Installation

Installing it auxiliary contact block is straightforward and typically requires basic electrical knowledge. Consult the user manual for detailed instructions.

Maintenance

Regular maintenance ensures optimal performance and longevity of the auxiliary contact block. Inspect for any signs of wear or damage and replace if necessary.

Conclusion

it auxiliary contact block is an essential component for expanding the functionality and control options of EasyPact TVS circuit breakers. Its 4NO configuration offers versatility and reliability in electrical applications.

FAQs

  1. What is the role of an auxiliary contact block?
  2. Can the LAEN40 be used with other circuit breaker brands?
  3. How do I integrate the auxiliary contact block into my existing setup?
  4. What safety features does EasyPact TVS offer?
  5. Where can I purchase Schneider electrical components?
Main
RangeEasy TeSys
range of productEasy TeSys Control
product or component typeAuxiliary contact block
device applicationSignalling
Device short nameLAEN
ColourGrey (RAL 7011)
Complementary
Range compatibilityEasyPact EasyPact TVS LC1E
Mounting locationFront
Auxiliary contacts operationInstantaneous
Pole contact composition4 NO
[Ui] rated insulation voltage690 V – for control circuit conforming to IEC 60947-5-1
[Ue] rated operational voltage<= 690 V
[Ith] conventional free air thermal current8 A (at 60 °C)
Irms rated making capacity140 A AC conforming to IEC 60947-5-1
[Icw] rated short-time withstand current100 A – 1 s
120 A – 500 ms
140 A – 100 ms
Protection typeGG fuse 10 A
Mechanical durability10 Mcycles
Minimum switching current5 mA
minimum switching voltage17 V
Non-overlap time1.5 ms on energisation no overlap between NC and NO contact
1.5 ms on de-energisation no overlap between NC and NO contact
Insulation resistance> 10 MOhm
Connections – terminalsControl circuit: screw clamp terminals 1 1 mm² – external diameter: 6 mm – cable stiffness: solid or flexible with cable end
Control circuit: screw clamp terminals 1 1 mm² – external diameter: 6 mm – cable stiffness: solid or flexible without cable end
Control circuit: screw clamp terminals 2 2.5 mm² – external diameter: 6 mm – cable stiffness: solid or flexible with cable end
Control circuit: screw clamp terminals 2 2.5 mm² – external diameter: 6 mm – cable stiffness: solid or flexible without cable end
net weight0.06 kg
Environment
Environmental characteristicStandard environment
StandardsIEC 60947-5-1
Product certificationsGOST
IP degree of protectionIP20 conforming to IEC 60529
Protective treatmentTH conforming to IEC 60068
Ambient air temperature for operation-5…55 °C
Ambient air temperature for storage-60…80 °C
Operating altitude3000 m without derating
Packing Units
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height4 cm
Package 1 Width4.8 cm
Package 1 Length5.6 cm
Package 1 Weight60 g

Main Document

Data Sheet : Download
