Schneider LC1DPKM7 | Capacitor contactor, TeSys D, 30 kVAR at 400 V/50 Hz, coil 220 V AC50/60 Hz
, , , ,

Schneider LC1DPKM7 | Capacitor contactor, TeSys D, 30 kVAR at 400 V/50 Hz, coil 220 V AC 50/60 Hz

Schneider Electric
Availability:

In stock

Add to wishlist
Compare

Schneider LC1DPKM7 | Capacitor contactor, TeSys D, 30 kVAR at 400 V/50 Hz, coil 220 V AC50/60 Hz

10,294.20 EGP 13,725.60 EGP

In stock

Compare

Schneider LC1DPKM7 | Capacitor contactor, TeSys D, 30 kVAR at 400 V/50 Hz, coil 220 V AC50/60 Hz

. Technical Specifications

  • Manufacturer: Schneider Electric

  • Series: TeSys D

  • Model: LC1DPKM7

  • Application: Capacitor switching contactor (for power factor correction)

  • Rated Power: 30 kVAR at 400 V / 50 Hz

  • Rated Operating Voltage: Up to 690 V AC

  • Coil Voltage: 220 V AC, 50/60 Hz

  • Utilization Category: AC-6b (suitable for capacitor banks)

  • Rated Current (AC-6b at 400 V): Approx. 43 A

  • Electrical Durability: Over 100,000 switching operations

  • Mechanical Durability: Over 5 million operations

  • Integrated Components:

    • Early-make auxiliary contacts

    • Pre-charge resistors for inrush current limitation

  • Mounting: DIN rail or panel-mounted with screws

  • Protection Degree: IP20 (enclosure), IP2x (terminals)

  • Standards: IEC 60947-4-1, IEC 60831

. Key Features

  • Designed specifically for capacitor bank switching with high inrush current suppression

  • Built-in resistors to reduce contact wear and electrical stress

  • Operates on 220 V AC control voltage (50/60 Hz)

  • Compact and modular design for seamless integration into PFC systems

  • Long service life with excellent mechanical and electrical endurance

. Typical Applications

The LC1DPKM7 is used in low-voltage power factor correction systems such as:

  • Automatic or fixed capacitor banks

  • Low-voltage distribution boards

  • Industrial facilities with inductive load compensation

  • Commercial buildings requiring reactive power compensation

  • Motor control centers (MCCs) with integrated power factor correction

Advantages

  • Handles high inrush currents safely and efficiently

  • Pre-installed resistors eliminate the need for external damping circuits

  • Compatible with Schneider TeSys D accessories and systems

  • Reliable operation in demanding electrical environments

  • Reduces maintenance requirements and extends capacitor life

  • Compliant with international standards for capacitor switching

SKU: LC1DPKM7 Categories: , , , , Brand:
Main
RangeTeSys
TeSys Deca
Product nameTeSys LC1D.K
TeSys Deca
Product or component typeCapacitor duty contactor
Device short nameLC1DPK
Device applicationControl
contactor applicationPower factor correction
utilisation categoryAC-6b
Poles description3P
power pole contact composition3 NO
device location in systemInside delta interruption
Line interruption
[Ue] rated operational voltagePower circuit: 690 V AC 50/60 Hz
Reactive power rating17 kvar at 230 V AC 50 Hz 60 °C
30 kvar at 400 V AC 50 Hz 60 °C
32 kvar at 440 V AC 50 Hz 60 °C
50 kvar at 690 V AC 50 Hz 60 °C
16.5 kvar at 230 V AC 60 Hz 60 °C
33.3 kvar at 460 V AC 60 Hz 60 °C
40 kvar at 575 V AC 60 Hz 60 °C
Control circuit typeAC at 50/60 Hz
[Uc] control circuit voltage220 V AC 50/60 Hz
Auxiliary contact composition1 NO + 2 NC instantaneous
Electrical durability300000 cycles at Ue 400 V
200000 cycles at Ue 690 V
mounting supportDIN rail
Plate
StandardsEN/IEC 60947-1
EN/IEC 60947-4-1
UL 60947-4-1
CSA C22.2 No 60947-4-1
IEC 60335-1
product certificationsIECEE CB Scheme
UL
CSA
UKCA
Connections – terminalsControl circuit: screw clamp terminals 1 1…4 mm² – cable stiffness: solid
Control circuit: screw clamp terminals 2 1…4 mm² – cable stiffness: solid
Control circuit: screw clamp terminals 1 1…4 mm² – cable stiffness: flexible without cable end
Control circuit: screw clamp terminals 2 1…4 mm² – cable stiffness: flexible without cable end
Control circuit: screw clamp terminals 1 1…4 mm² – cable stiffness: flexible with cable end
Control circuit: screw clamp terminals 2 1…2.5 mm² – cable stiffness: flexible with cable end
Power circuit: EverLink BTR screw connectors 1 1…35 mm² – cable stiffness: solid
Power circuit: EverLink BTR screw connectors 2 1…25 mm² – cable stiffness: solid
Power circuit: EverLink BTR screw connectors 1 1…35 mm² – cable stiffness: flexible with or without cable end
Power circuit: EverLink BTR screw connectors 2 1…25 mm² – cable stiffness: flexible with or without cable end
Tightening torqueControl circuit: 1.7 N.m – on screw clamp terminals
Power circuit: 5 N.m – on EverLink BTR screw connectors – cable 1…25 mm²
Power circuit: 8 N.m – on EverLink BTR screw connectors – cable 35 mm²
Maximum operating rate240 cyc/h
Complementary
Auxiliary contacts typeType mechanically linked 1 NO + 2 NC conforming to IEC 60947-5-1
Environment
IP degree of protectionIP20 front face conforming to IEC 60529
ambient air temperature for operation-5…60 °C
Ambient air temperature for storage-60…80 °C
Operating altitude0…3000 m
height166 mm
Width55 mm
Depth156 mm
Net weight1.3 kg
Packing Units
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height7.000 cm
Package 1 Width20.000 cm
Package 1 Length23.000 cm
Package 1 Weight1.108 kg
Unit Type of Package 2S03
Number of Units in Package 26
Package 2 Height30.000 cm
Package 2 Width30.000 cm
Package 2 Length40.000 cm
Package 2 Weight7.173 kg
Unit Type of Package 3P06
Number of Units in Package 348
Package 3 Height75.000 cm
Package 3 Width60.000 cm
Package 3 Length80.000 cm
Package 3 Weight67.388 kg
Contractual warranty
Warranty18 months

Main Document

Data Sheet : LC1DPKM7
