Schneider LV510301 | circuit breaker EasyPact CVS100B, 25 kA at 415 VAC, 25 A rating thermal magnetic TM-D trip unit, 3P 3d
Original price was: 12,608.47 EGP.7,502.04 EGPCurrent price is: 7,502.04 EGP.
Shipping calculated at checkout.
Introducing the LV510301 Schneider Electric Circuit Breaker
The LV510301 from Schneider Electric is designed to meet the needs of modern electrical systems, providing superior safety and reliability. This circuit breaker combines a thermal magnetic TM-D trip unit with a 25 A rating, making it an essential component for any electrical installation. Whether you are upgrading your current systems or setting up new installations, this product is engineered to deliver consistent and dependable performance.
Why Choose the Schneider LV510301?
Choosing the LV510301 means investing in a product that prioritizes your safety and the longevity of your electrical systems. With a breaking capacity of 25 kA at 415 VAC, this circuit breaker ensures that your circuits are protected against overloads and short circuits. Its robust design not only enhances safety but also minimizes downtime, ensuring that your operations run smoothly without interruptions.
Enhanced Performance and Reliability
One of the standout benefits of the LV510301 is its ability to adapt to various load conditions. The thermal magnetic trip unit works effectively to detect overload conditions and provide quick disconnections, thereby reducing the risk of damage to your equipment. This feature is particularly valuable in environments where electrical loads can fluctuate significantly.
Simple Installation and Maintenance
Installation of the LV510301 is straightforward, allowing electrical professionals to set it up quickly and efficiently. The design incorporates user-friendly features that simplify the wiring process, making it suitable for both seasoned electricians and those new to circuit breaker installations. Furthermore, maintaining this circuit breaker is hassle-free, ensuring that your equipment remains in optimal condition with minimal effort.
Compliance with Industry Standards
Schneider Electric is recognized for its commitment to quality and safety standards. The LV510301 adheres to rigorous industry regulations, providing peace of mind that your electrical systems are compliant and secure. This assurance helps reduce liability and fosters a safer work environment.
Conclusion
In summary, the LV510301 from Schneider Electric is not just a circuit breaker; it is a comprehensive solution for anyone looking to enhance their electrical systems’ safety and efficiency. With its high breaking capacity, robust design, and ease of use, this circuit breaker is an investment that pays off in long-term reliability and performance. Make the smart choice today and select the LV510301 for your electrical protection needs.
| Range | EasyPact |
|---|---|
| Range of product | EasyPact CVS100...250 |
| Product name | EasyPact CVS |
| Device short name | CVS100B |
| Product or component type | Circuit breaker |
| Device application | Distribution |
| poles description | 3P |
| Protected poles description | 3D |
| Earth leakage protection (Vigi add on) | Without |
| [In] rated current | 25 A at 40 °C |
| network type | AC |
| Utilisation category | Category A |
| [Icu] Breaking capacity | 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 |
| Trip unit name | TM-D |
| Trip unit technology | Thermal-magnetic |
| Trip unit rating | 25 A at 40 °C |
| Protection type | Short-circuit protection (magnetic) Overload protection (thermal) |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 |
|---|---|
| network frequency | 50/60 Hz |
| Breaking capacity code | B |
| [Ics] rated service breaking capacity | 15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Mechanical durability | 30000 cycles |
| Electrical durability | 12000 cycles 415 V In conforming to IEC 60947-2 |
| Control type | Toggle |
| Thermal protection adjustment range | 17.5…25 A |
| Long time pick-up adjustment type Ir | Adjustable |
| Long time pick-up adjustment range | 0.7...1 x In |
| Long time delay adjustment type | Fixed |
| Instantaneous pick-up adjustment type Ii | Fixed |
| instantaneous pick-up adjustment range | 300 A |
| Contact position indicator | Yes |
| mounting support | Backplate |
| mounting mode | Fixed |
| Upside connection | Front |
| downside connection | Front |
| Connections - terminals | Screw connection |
| Connection pitch | 35 mm |
| Compatibility code | CVS100 |
| Width | 105 mm |
| Depth | 86 mm |
| Height | 161 mm |
| Net weight | 1.5 kg |
| Standards | IEC 60947-2 EN 60947-2 |
|---|---|
| Product certifications | IEC GOST |
| Electrical shock protection class | Class II |
| Pollution degree | 3 conforming to IEC 60664-1 |
| IP degree of protection | IP40 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 11.000 cm |
| Package 1 Width | 13.500 cm |
| Package 1 Length | 19.000 cm |
| Package 1 Weight | 1.720 kg |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 6 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 10.740 kg |
| Unit Type of Package 3 | P12 |
| Number of Units in Package 3 | 48 |
| Package 3 Height | 45.000 cm |
| Package 3 Width | 80.000 cm |
| Package 3 Length | 120.000 cm |
| Package 3 Weight | 97.920 kg |
Data Sheet : Download
Related products
Sale!
In stock
Schneider LV510334 Easypact | circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 50 A rating thermal magnetic TM-D trip unit, 3P 3d
Original price was: 14,438.56 EGP.8,688.20 EGPCurrent price is: 8,688.20 EGP.Sale!
Out of stock
Schneider LV516648 Easypact | CVS160F TM160D 4P4D circuit breaker 50d
Original price was: 25,329.20 EGP.15,241.50 EGPCurrent price is: 15,241.50 EGP.Sale!
Out of stock
Schneider LV516303 25 kA | circuit breaker EasyPact CVS160B, 25 kA at 415 VAC, 160 A rating thermal magnetic TM-D trip unit, 3P 3d
Original price was: 18,664.15 EGP.11,105.17 EGPCurrent price is: 11,105.17 EGP.Sale!
In stock
Schneider LV510330 | Easypact CVS – CVS100F TM16D circuit breaker – 3P/3d
Original price was: 14,767.09 EGP.8,786.42 EGPCurrent price is: 8,786.42 EGP.Sale!
Out of stock
Schneider LV510473 | Easypact CVS – CVS100N circuit breaker – 3P/3d
