Schneider LX1FJ220 | TeSys F – contactor coil – LX1FJ – 220…230 V AC 40…400 Hz

Schneider Electric
Availability:

Out of stock


16,014 EGP 29,116 EGP

Out of stock

Compare

Schneider LX1FJ220 | TeSys F – contactor coil – LX1FJ – 220…230 V AC 40…400 Hz

Schneider LX1FJ220 Description

Introduction

TeSys F AC coil 220/230V 40-400Hz (voltage code M7/P7), low sealed consumption, for TeSys F 3-pole and 4-pole contactors LC1F400. It operates in voltage limits 0.85-1.1 Uc and environments until 55°C. It provides high operating rates to the contactor, until 2400 cycles/hour. Green Premium compliant (RoHS/REACh)

Schneider Electric is a renowned name in the world of electrical systems, known for its innovative solutions and reliable products. One such product that stands out is the Schneider LX1FJ220. This article delves into the intricacies of this component, its features, applications, and much more.

Understanding the Schneider LX1FJ220

What is the Schneider LX1FJ220?

The Schneider LX1FJ220 is a contactor coil designed for use in electrical control systems. It plays a crucial role in managing the operations of contactors, which are essential for controlling large electrical loads. This component is engineered to provide high performance and reliability in various applications.

Key Features and Specifications

The Schneider LX1FJ220 is known for its robust construction and reliable performance. Some of its key features include:

  • High-quality insulation
  • Compatibility with a wide range of contactors
  • Efficient energy consumption
  • Easy installation and maintenance

Design and Build Quality

Materials Used

Schneider Electric uses premium materials to ensure the LX1FJ220 meets high standards of durability and reliability. The coil is made with high-grade copper and insulation materials that resist wear and tear, providing longevity.

Durability and Reliability

Designed to withstand harsh conditions, the LX1FJ220 boasts exceptional durability. It is built to handle high voltage and current, making it suitable for demanding industrial environments.

Technical Specifications

Voltage and Current Ratings

The Schneider LX1FJ220 operates at a voltage range of 24V to 240V, catering to different system requirements. Its current rating ensures it can handle substantial electrical loads without compromising performance.

Size and Dimensions

Compact and efficient, the LX1FJ220’s size allows for easy integration into various control panels. Its dimensions are designed to save space while ensuring optimal functionality.

Installation and Setup

Step-by-Step Installation Guide

  1. Turn off the power: Ensure all power sources are turned off to avoid electrical hazards.
  2. Mount the coil: Attach the LX1FJ220 securely to the designated location.
  3. Connect the wires: Follow the wiring diagram to connect the coil to the contactor.
  4. Secure connections: Double-check all connections to ensure they are tight and secure.
  5. Test the installation: Restore power and test the system to ensure proper operation.

Safety Precautions

  • Always follow manufacturer guidelines.
  • Use appropriate personal protective equipment (PPE).
  • Double-check all connections before powering up.

Applications of Schneider LX1FJ220

Industrial Use Cases

The LX1FJ220 is widely used in industrial settings to control heavy machinery and equipment. Its robust design makes it ideal for handling the high demands of manufacturing processes.

Commercial Applications

In commercial environments, the LX1FJ220 helps manage electrical loads in buildings, ensuring efficient energy distribution and control.

Residential Applications

Although more common in industrial and commercial settings, the LX1FJ220 can also be used in residential systems for managing complex electrical setups.

Benefits of Using Schneider LX1FJ220

Efficiency and Performance

The LX1FJ220 is designed to deliver exceptional efficiency, ensuring minimal energy wastage and optimal performance. Its reliable operation reduces downtime and maintenance costs.

Cost-Effectiveness

Investing in the LX1FJ220 offers long-term cost benefits due to its durability and low maintenance requirements. It provides excellent value for money by enhancing the overall efficiency of electrical systems.

Comparison with Competitors

Key Differences with Similar Products

Compared to other contactor coils, the LX1FJ220 stands out due to its superior build quality and performance. It offers better energy efficiency and a longer lifespan than many competing products.

Advantages of Schneider LX1FJ220

The Schneider LX1FJ220 is favored for its easy installation, robust design, and reliable performance. Its compatibility with a wide range of contactors adds to its versatility, making it a preferred choice for many.

Maintenance and Troubleshooting

Regular Maintenance Tips

  • Inspect regularly: Check the coil and connections periodically to ensure they are in good condition.
  • Clean the components: Keep the coil and surrounding areas free from dust and debris.
  • Tighten connections: Ensure all electrical connections remain secure over time.

Common Issues and Solutions

  • Overheating: Ensure proper ventilation and check for any overloading conditions.
  • Loose connections: Regularly inspect and tighten all electrical connections.

Customer Reviews and Feedback

User Experiences

Users have praised the LX1FJ220 for its reliability and ease of installation. Many have noted its superior performance in various applications, from industrial to commercial settings.

Common Praises and Complaints

Praises:

  • High durability
  • Efficient performance
  • Easy installation

Complaints:

  • Higher initial cost compared to some alternatives
  • Availability issues in certain regions

Where to Buy Schneider LX1FJ220

Authorized Dealers

Purchasing from authorized dealers ensures you receive a genuine product. Schneider Electric’s website provides a list of authorized dealers.

Online Platforms

The LX1FJ220 is also available on various online platforms such as Amazon, eBay, and specialized electrical supply stores.

SKU: LX1FJ220 Categories: ,
Main
Range TeSys
Product or component type Contactor coil
Device short name LX1FJ
Range compatibility TeSys TeSys F LC1F contactor
Product compatibility LC1F400
Control circuit type AC at 40…400 Hz
[Uc] control circuit voltage 220…230 V AC 40…400 Hz
Inductance of closed circuit 5.1 H
Average resistance 37 Ohm inrush at 20 °C
1030 Ohm holding at 20 °C
Operating time 100…170 ms opening
40…75 ms closing
Mechanical durability 10 Mcycles
Maximum operating rate 2400 cyc/h 55 °C
Complementary
Coil technology Without built-in suppressor module
Control circuit voltage limits Operational: 0.85…1.1 Uc 40…400 Hz (at 55 °C)
Drop-out: 0.3…0.5 Uc 40…400 Hz (at 55 °C)
Inrush power in VA 1075 VA 40…400 Hz cos phi 0.9 (at 20 °C)
Hold-in power consumption in VA 15 VA 40…400 Hz cos phi 0.3 (at 20 °C)
Heat dissipation 14 W at 40…400 Hz
Environment
ambient air temperature for operation -5…55 °C
Net weight 1 kg
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 9.500 cm
Package 1 Width 10.000 cm
Package 1 Length 19.000 cm
Package 1 Weight 1.154 kg
Unit Type of Package 2 S03
Number of Units in Package 2 6
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 7.368 kg
Unit Type of Package 3 P06
Number of Units in Package 3 48
Package 3 Height 75.000 cm
Package 3 Width 60.000 cm
Package 3 Length 80.000 cm
Package 3 Weight 66.140 kg
Contractual warranty
Warranty 12 months

Main Document

Data Sheet : LX1FJ220
