Schneider R9R51263 | Residual current circuit breaker (RCCB), Resi9, 2P, 63A, AC type, 30mA

Schneider Electric
Availability:

In stock


2,612 EGP 4,282 EGP

In stock

Compare

Schneider R9R51263 | Residual current circuit breaker (RCCB), Resi9, 2P, 63A, AC type, 30mA

This is a Resi9 RCCB residual current circuit breaker (RCCB). It is a 2P circuit breaker with In rated current of 63A, AC type protection class and a 30mA earth leakage sensitivity. This product protects against electrical shock by direct or indirect contact and fire hazards. As an high sensitivity residual current circuit breaker, it is recommended for all power sockets. It is also compulsory for all equipment in bathrooms, outdoors. The Resi9 is targeted to the residential market for individual and collective buildings. This product is compliant with EN/IEC 61008-2-1 standard. The (Inc/IΔc) conditional rated short circuit current is 6000 A. The (Im/IΔm) rated making and breaking capacity is 630A. The electrical endurance is up to 10000 cycles. The mechanical endurance is up to 20000 cycles. The Ue operational voltage is 230VAC. It is DIN rail mountable. The width in 9mm pitches is 4. The product colour is white (RAL9003). The dimensions are (W) 36mm x (H) 81mm x (D) 73mm. It has an IP20 degree of protection. It becomes IP40 once in modular enclosure according to IEC/EN 60529 standard. The operating temperature is from -5°C to 40°C. The storage temperature is from -40°C to 80°C.

Introduction

Residual Current Circuit Breakers (RCCBs) play a crucial role in electrical safety, particularly in residential and commercial settings. Understanding their features, specifications, and installation process is essential for ensuring a safe electrical environment.

Schneider R9R51263

Schneider R9R51263 is a specific model of RCCB designed to provide effective protection against electrical faults. It belongs to the Resi9 series, offering reliable performance and safety features.

How RCCBs Work

RCCBs monitor the imbalance of electrical currents between the live and neutral wires. When an imbalance occurs, indicating a leakage or fault, the RCCB quickly trips, cutting off the power supply and preventing potential electrical hazards such as electric shocks or fires.

Types of RCCBs

There are different types of RCCBs based on their operational characteristics, including AC type, DC type, and selective RCCBs. Understanding these types helps in choosing the right one for specific applications.

Importance in Safety

RCCBs are indispensable for electrical safety as they provide protection against electric shocks, fire hazards, and equipment damage. Their ability to detect even small leakages ensures a high level of safety.

Installation Process

Installing an RCCB involves several steps such as identifying the electrical panel, switching off the power, connecting the RCCB in the circuit, and testing its functionality. Professional installation is recommended for accuracy and safety.

Maintenance Tips

Regular maintenance of RCCBs is essential to ensure they function correctly when needed. This includes periodic testing, checking for physical damage, and promptly replacing any faulty units.

Common FAQs

  1. What is the difference between an RCCB and an MCB?
    • An RCCB monitors current imbalances, while an MCB (Miniature Circuit Breaker) protects against overloads and short circuits.
  2. Do RCCBs need to be reset after tripping?
    • Yes, after an RCCB trips due to a fault, it needs to be manually reset to restore power.
  3. Can RCCBs be installed outdoors?
    • Yes, there are weatherproof RCCB models designed for outdoor installations.
  4. What is the typical lifespan of an RCCB?
    • RCCBs have a long lifespan, often lasting over a decade with proper maintenance.
  5. Are RCCBs mandatory in all electrical installations?
    • Regulations may vary by location, but RCCBs are generally recommended for enhanced safety in modern electrical systems.
SKU: R9R51263 Category:
Main
Range Resi9
Product or component type Residual current circuit breaker (RCCB)
Poles description 2P
[In] rated current 63 A
Network type AC
Earth-leakage sensitivity 30 mA
earth-leakage protection time delay Instantaneous
Earth-leakage protection class Type AC
Rated breaking and making capacity Im 630 A conforming to EN/IEC 61008
Rated conditional short-circuit current Inc 6 kA
Quality labels EAC
UA TR
Complementary
Network frequency 50/60 Hz
[Ue] rated operational voltage 230 V AC 50/60 Hz
Residual current tripping technology Voltage independent
[Ui] rated insulation voltage 440 V
[Uimp] rated impulse withstand voltage 4 kV
Surge current 250 A
control type Toggle
local signalling ON/OFF indication
Mounting mode Clip-on
mounting support DIN rail
9 mm pitches 4
height 81 mm
Width 36 mm
Depth 73 mm
Net weight 180 g
Embedding depth 44 mm
Colour White
Mechanical durability 20000 cycles
Electrical durability 10000 cycles
Connections – terminals Tunnel type terminals (top or bottom) – 1…35 mm² – rigid
Tunnel type terminals (top or bottom) – 1…25 mm² – flexible
Tunnel type terminals (top or bottom) – 1…25 mm² – flexible with ferrule
Wire stripping length 15 mm for top or bottom connection
Tightening torque 3.5 N.m top or bottom
Environment
Standards EN/IEC 61008-1
EN/IEC 61008-2-1
IP degree of protection IP20
Pollution degree 2
Overvoltage category III
Tropicalisation 2 conforming to IEC 60068-1
Relative humidity 95 % at 55 °C
Ambient air temperature for operation -5…40 °C
Ambient air temperature for storage -40…80 °C
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 4.000 cm
Package 1 Width 8.500 cm
Package 1 Length 9.000 cm
Package 1 Weight 215.000 g
Unit Type of Package 2 S03
Number of Units in Package 2 54
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 12.004 kg
Unit Type of Package 3 P12
Number of Units in Package 3 432
Package 3 Height 45.000 cm
Package 3 Width 80.000 cm
Package 3 Length 120.000 cm
Package 3 Weight 108.032 kg

Main Document

Data Sheet : Download
