Schneider TMC2AI2 | cartridge M221 – 2 analog inputs – I/O extension
In stock
Schneider TMC2AI2 | cartridge M221 – 2 analog inputs – I/O extension
5,238 EGP 9,523 EGP
In stock
CompareSchneider TMC2AI2 | cartridge M221 – 2 analog inputs – I/O extension
Schneider TMC2AI2 Description
Introduction
Schneider Electric is a globally recognized leader in energy management and automation solutions. The Schneider TMC2AI2 is a versatile and high-performing model, designed to meet the needs of various industrial applications with precision and reliability.
Specifications of Schneider TMC2AI2
The Schneider TMC2AI2 is equipped with a range of advanced technical specifications. These include high precision in analog input/output, robust communication interfaces, and extensive compatibility with other industrial equipment, ensuring seamless integration and operation.
Design and Build Quality
Constructed with high-quality materials, the Schneider TMC2AI2 ensures durability and longevity. Its compact design allows for easy installation in tight spaces, while its robust construction enables it to withstand harsh industrial environments, ensuring reliable performance over time.
Performance and Efficiency
This model is engineered to deliver exceptional performance and efficiency. The TMC2AI2 boasts advanced power management features that optimize energy consumption, providing high operational efficiency without sacrificing performance. Its precision in analog input/output makes it ideal for applications requiring accurate data processing.
Installation and Setup
The installation of the Schneider TMC2AI2 is straightforward, supported by comprehensive setup guides and technical support. Whether integrating it into a new system or upgrading an existing one, the TMC2AI2 simplifies the process, ensuring a smooth and hassle-free setup.
User Interface and Controls
The user interface of the Schneider TMC2AI2 is designed for ease of use. It features intuitive controls that allow users to quickly navigate through settings and functions, ensuring efficient operation. Both novice users and experienced professionals will find the interface user-friendly and straightforward.
Safety Features
Safety is paramount with the Schneider TMC2AI2. It includes several built-in safety mechanisms, such as over-voltage protection and thermal regulation, ensuring safe and reliable operation. The model complies with stringent industry safety standards, providing peace of mind for users.
Maintenance and Care
Maintaining the Schneider TMC2AI2 is simple and straightforward. Regular maintenance practices are recommended to ensure optimal performance and longevity. Following the provided guidelines helps in maintaining the unit’s reliability and extending its service life.
Applications and Use Cases
The Schneider TMC2AI2 is versatile and suitable for a wide range of industrial applications. Its high precision in analog input/output makes it ideal for sectors such as manufacturing, energy management, and process automation, where accurate data handling is critical.
Comparative Analysis
When compared to other models in Schneider Electric’s lineup, the TMC2AI2 stands out due to its advanced features and high efficiency. While it may come at a higher initial cost, its superior performance and long-term reliability make it a worthwhile investment for industrial applications.
Customer Reviews and Feedback
Users of the Schneider TMC2AI2 have expressed high satisfaction with its accuracy, reliability, and ease of use. Customer feedback highlights the model’s durable construction and efficient performance, making it a preferred choice for various industrial settings.
Price and Value Proposition
The Schneider TMC2AI2 is competitively priced, offering excellent value for its advanced features and high performance. Though it may be more expensive than some alternatives, its efficiency, precision, and reliability justify the investment, providing significant long-term value.
Future Developments and Upgrades
Schneider Electric is committed to innovation and continuous improvement. Future upgrades for the TMC2AI2 could include enhanced connectivity options, increased processing power, and additional safety features. Keeping abreast of these developments can provide further benefits.
Conclusion
In conclusion, the Schneider TMC2AI2 is a top-tier model that combines advanced features, robust performance, and reliability. Its design, efficiency, and safety features make it an excellent choice for a wide range of industrial applications, ensuring precise and reliable analog input/output operations.
| brands |
|---|
| Range of product | Modicon M221 |
|---|---|
| Product or component type | Analogue input cartridge |
| Product compatibility | Modicon M221C |
| Analogue input number | 2 |
| Analogue input type | current 4…20 mA current 0…20 mA voltage 0…10 V |
|---|---|
| Analogue input resolution | 12 bits |
| LSB value | 2.44 mV 0…10 Vvoltage 4.88 µA 0…20 mAcurrent 3.91 µA 4…20 mAcurrent |
| Conversion time | 20 ms |
| Sampling duration | 10 ms |
| Absolute accuracy error | +/- 0.1 % of full scale at 25 °C +/- 1 % of full scale |
| Temperature drift | +/- 0.02 %FS/°C |
| Repeat accuracy | +/- 0.5 %FS |
| Non-linearity | +/- 0.01 %FS |
| Cross talk | <= 1 LSB |
| type of cable | Twisted shielded pairs cable |
| Electrical connection | 3 x 1.5 mm² 2 screw terminal blocks with pitch 3.81 mm adjustment for inputs |
| Maximum cable distance between devices | Twisted shielded pairs cable: <30 m for input |
| Insulation | Non-insulated between analogue input and internal logic |
| Height | 41 mm |
| Depth | 15 mm |
| Width | 35 mm |
| Net weight | 0.015 kg |
| Permissible continuous overload | 13 V, analogue input type: voltage 40 mA, analogue input type: current |
| Input impedance | <= 250 Ohm current >= 1 MOhm voltage |
| Immunity to microbreaks | 10 ms |
|---|
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.594 cm |
| Package 1 Width | 4.692 cm |
| Package 1 Length | 7.059 cm |
| Package 1 Weight | 30.0 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 75 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 3.31 kg |
| Unit Type of Package 3 | P12 |
| Number of Units in Package 3 | 2400 |
| Package 3 Height | 75 cm |
| Package 3 Width | 120 cm |
| Package 3 Length | 80 cm |
| Package 3 Weight | 111 kg |
