Schneider XB4BV64 | Pilot light, metal, red, Ø22, plain lens with BA9s bulb, <= 250 V
In stock
453 EGP 781 EGP
In stock
CompareSchneider XB4BV64 | Pilot light, metal, red, Ø22, plain lens with BA9s bulb, <= 250 V
Schneider XB4BV64 | Pilot light, metal, red, Ø22, plain lens with BA9s bulb, <= 250 V description
Introduction
The Schneider XB4BV64 pilot light is a versatile and reliable component designed for industrial applications. This article provides an in-depth look at its features, benefits, and applications.
Design
The XB4BV64 features a robust metal construction, ensuring durability and longevity even in harsh industrial environments.
Light Color
The pilot light emits a vibrant red light, making it easily visible in various working conditions.
Size and Lens
With a diameter of Ø22, the XB4BV64 is compact yet highly functional. Its plain lens incorporates a BA9s bulb, providing efficient and clear illumination.
Voltage
Operating at a voltage of <= 250 V, this pilot light is suitable for a wide range of electrical systems.
Features
One of the standout features of the XB4BV64 is its long-lasting performance. The combination of quality materials and design ensures reliability over extended periods.
Installation
Installing the XB4BV64 is straightforward, thanks to its user-friendly design. It can be easily integrated into existing setups without extensive modifications.
Applications
This pilot light is ideal for industrial use, including machinery control panels, equipment monitoring, and status indication.
Benefits
The XB4BV64 offers several benefits to users, including enhanced safety through clear visual indicators and reliable performance under demanding conditions.
Comparison
Compared to traditional pilot lights, the Schneider XB4BV64 stands out for its durability, visibility, and ease of maintenance.
Maintenance
Routine maintenance of the XB4BV64 is simple, ensuring continued performance and minimizing downtime in industrial settings.
Conclusion
In conclusion, the Schneider XB4BV64 pilot light combines durability, visibility, and ease of use, making it a valuable component for industrial applications.
FAQs
- What is the voltage rating of the Schneider XB4BV64?
- The voltage rating is <= 250 V, suitable for various electrical systems.
- Can the XB4BV64 be used outdoors?
- Yes, it can be used outdoors but should be protected from extreme weather conditions.
- Is the BA9s bulb replaceable?
- Yes, the BA9s bulb can be replaced if needed, ensuring continued functionality.
- How long does the XB4BV64 typically last?
- With proper maintenance, the XB4BV64 can last for many years of continuous use.
- Does Schneider provide installation guides for the XB4BV64?
- Yes, detailed installation guides are available to ensure correct and safe installation.
| Range of Product | Harmony XB4 |
|---|---|
| Product or Component Type | Pilot light |
| Device short name | XB4 |
| Bezel material | Chromium plated metal |
| Fixing collar material | Zamak |
| Head type | Standard |
| Mounting diameter | 0.9 in (22.5 mm) |
| Sale per indivisible quantity | 1 |
| Shape of signaling unit head | Round |
| cap/operator or lens colour | Red |
| Operator additional information | With plain lens |
| Light source | Bulb not included |
| Bulb base | BA 9s |
| Light block supply | Direct <2.4 W |
| [Us] rated supply voltage | <= 250 V |
| Height | 1.9 in (47 mm) |
|---|---|
| Width | 1.2 in (30 mm) |
| Depth | 2.2 in (55 mm) |
| Terminals description ISO n°1 | (X1-X2)PL |
| Net Weight | 0.165 lb(US) (0.075 kg) |
| Resistance to high pressure washer | 1015.3 psi (7000000 Pa) 131 °F (55 °C) 0.1 m |
| Connections – terminals | Screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 Screw clamp terminals, 1 x 0.22…2 x 2.5 mm² without cable end IEC 60947-1 |
| [Ui] rated insulation voltage | 250 V 3)IEC 60947-1 |
| [Uimp] rated impulse withstand voltage | 4 kV IEC 60947-1 |
| Signalling type | Steady |
| Device presentation | Complete product |
| Protective treatment | TH |
|---|---|
| Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
| Ambient Air Temperature for Operation | -40…131 °F (-40…55 °C) |
| Electrical shock protection class | Class I IEC 60536 |
| IP degree of protection | IP66 IEC 60529 IP67 IP69 IP69K |
| NEMA degree of protection | NEMA 13 NEMA 4X |
| IK degree of protection | IK06 conforming to IEC 50102 |
| Standards | UL 508 JIS C8201-5-1 IEC 60947-5-1 CSA C22.2 No 14 IEC 60947-1 IEC 60947-5-4 IEC 60947-5-5 JIS C8201-1 |
| Product Certifications | UL Listed CSA |
| Vibration resistance | 5 gn 12…500 Hz)IEC 60068-2-6 |
| Shock resistance | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
| Category | US10CS222468 |
|---|---|
| Discount Schedule | 0CS2 |
| GTIN | 3389110887198 |
| Returnability | Yes |
| Country of origin | MX |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.465 in (8.800 cm) |
| Package 1 Width | 1.339 in (3.400 cm) |
| Package 1 Length | 2.126 in (5.400 cm) |
| Package 1 Weight | 2.610 oz (74.000 g) |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 5 |
| Package 2 Height | 3.465 in (8.800 cm) |
| Package 2 Width | 1.339 in (3.400 cm) |
| Package 2 Length | 10.433 in (26.500 cm) |
| Package 2 Weight | 13.016 oz (369.000 g) |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 150 |
| Package 3 Height | 11.811 in (30.000 cm) |
| Package 3 Width | 11.811 in (30.000 cm) |
| Package 3 Length | 15.748 in (40.000 cm) |
| Package 3 Weight | 25.503 lb(US) (11.568 kg) |
| Warranty | 18 months |
|---|
