Schneider XB5FA51 | Antimicrobial Push button flush mounted, Harmony XB5, plastic, yellow, 30mm, spring return, unmarked, 1NO

Schneider Electric
Availability:

In stock


421 EGP 725 EGP

In stock

Compare

Schneider XB5FA51 | Antimicrobial Push button flush mounted, Harmony XB5, plastic, yellow, 30mm, spring return, unmarked, 1NO

Schneider XB5FA51?

The Schneider XB5FA51 is a type of push-button switch widely used in various industrial applications. It’s designed to provide reliable and efficient control over electrical circuits, making it a vital component in automation systems. This push-button is part of Schneider Electric’s Harmony XB5 range, known for its robustness and versatility.

Design and Construction

The Schneider XB5FA51 boasts a durable construction that ensures longevity even in harsh industrial environments. The materials used in its design include high-quality plastics and metals that resist wear and tear, ensuring the device can withstand regular use and adverse conditions. The design also focuses on user safety, featuring a secure and easy-to-operate mechanism.

Technical Specifications

When it comes to technical specs, the Schneider XB5FA51 is designed to meet high standards. It operates with a rated operational voltage of up to 240V and a rated operational current of 3A. The mechanical lifespan of this push-button switch is impressive, withstanding up to 1 million operations, which speaks volumes about its reliability.

Functionalities and Applications

The versatility of the Schneider XB5FA51 makes it suitable for a wide range of applications. It’s commonly used in control panels, machinery, and automation systems. Whether it’s starting or stopping a machine, this push-button switch provides a simple yet effective interface for various industrial operations.

Compatibility and Integrations

One of the significant advantages of the Schneider XB5FA51 is its compatibility with a wide range of devices and systems. It seamlessly integrates with other Schneider Electric products and various third-party devices, making it a versatile choice for different setups.

Advantages of Using Schneider XB5FA51

There are several reasons why the Schneider XB5FA51 is a popular choice:

  • Efficiency: It ensures quick and reliable operations.
  • Cost-effectiveness: Its long lifespan and minimal maintenance needs make it a cost-effective solution.
  • Ease of use: The design is user-friendly, allowing easy operation and installation.

Environmental Impact

Schneider Electric is committed to sustainability, and the XB5FA51 is no exception. It’s designed with eco-friendly materials and processes, ensuring minimal environmental impact. The device also supports energy-efficient operations, contributing to overall sustainability goals.

Pricing and Availability

The Schneider XB5FA51 is competitively priced, offering great value for its features and reliability. It’s widely available through various distributors and online platforms. For the best deals, purchasing directly from authorized Schneider Electric distributors is recommended.

Main
Range of ProductHarmony XB5
Product or Component TypePush-button
Device short nameXB5F
Product CompatibilityZBYF2101
ZBYF4101
ZBYF6101
ZBYF6102
ZBZF32
ZBZF33
ZB4FBZ007
bezel materialPlastic
Dark grey plastic
Head typeBuilt-in-flush
Fixing collar materialPlastic
Mounting diameter1.20 in (30.5 mm)
Sale per indivisible quantity1
Shape of signaling unit headRound
Type of operatorSpring return
Operator profileYellow flush, unmarked
Contacts type and composition1 NO
contact operationSlow-break
Connections – terminalsScrew clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1
Screw clamp terminals, 1 x 0.22…2 x 2.5 mm² without cable end IEC 60947-1
Complementary
Height1.65 in (42 mm)
Width1.44 in (36.6 mm)
Depth2.17 in (55 mm)
Terminals description ISO n°1(13-14)NO
Resistance to high pressure washer1015.26 psi (7000000 Pa) 131 °F (55 °C) 0.1 m
contacts usageStandard contacts
Positive openingWithout
Operating travel0.10 in (2.6 mm) NO changing electrical state)
0.17 in (4.3 mm) total travel)
Operating force3.8 N NO changing electrical state
Mechanical durability10000000 cycles
Tightening torque7.08…10.62 lbf.in (0.8…1.2 N.m) IEC 60947-1
Shape of screw headCross Philips no 1
Cross pozidriv No 1
Slotted flat Ø 4 mm
Slotted flat Ø 5.5 mm
Contacts materialSilver alloy (Ag/Ni)
Short-circuit protection10 A cartridge fuse gG IEC 60947-5-1
[Ith] conventional free air thermal current10 A IEC 60947-5-1
[Ui] rated insulation voltage600 V 3)IEC 60947-1
[Uimp] rated impulse withstand voltage6 kV IEC 60947-1
[Ie] rated operational current3 A 240 V, AC-15, A600 IEC 60947-5-1
6 A 120 V, AC-15, A600 IEC 60947-5-1
0.1 A 600 V, DC-13, Q600 IEC 60947-5-1
0.27 A 250 V, DC-13, Q600 IEC 60947-5-1
0.55 A 125 V, DC-13, Q600 IEC 60947-5-1
1.2 A 600 V, AC-15, A600 IEC 60947-5-1
Electrical durability1000000 cycles AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
1000000 cycles AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
1000000 cycles AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
1000000 cycles DC-13, 0.2 A 110 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
1000000 cycles DC-13, 0.5 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
Electrical reliabilityΛ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4
Λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
device presentationComplete product
CustomizableNo
Customizable1
GCR BRIDGEXB5FACUST01
Compatibility codeXB5
Environment
Protective treatmentTH
Ambient Air Temperature for Storage-40…158 °F (-40…70 °C)
Ambient Air Temperature for Operation-40…158 °F (-40…70 °C)
Overvoltage categoryClass II IEC 60536
IP degree of protectionIP66 IEC 60529
IP67
IP69
IP69K
Type 13 UL 50 E
Type 12 UL 50 E
Type 4 UL 50 E
Type 4X UL 50 E
NEMA degree of protectionNEMA 13
NEMA 4X
IK degree of protectionIK03 IEC 50102
StandardsIEC 60947-1
UL 508
JIS C8201-5-1
IEC 60947-5-4
IEC 60947-5-1
CSA C22.2 No 14
JIS C8201-1
ISO 22196:2011
ISO 21702
Product CertificationsUL Listed
CSA
Vibration resistance5 gn 2…500 Hz)IEC 60068-2-6
2 mm peak to peak 2…10 Hz)IEC 60068-2-6
Shock resistance30 gn 18 ms) half sine wave acceleration IEC 60068-2-27
50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27
Ordering and shipping details
Category22467-PUSHBUTTONS,22MM(PLASTIC) NEW
Discount ScheduleCS2
GTIN3606481360526
ReturnabilityYes
Packing Units
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height3.39 in (8.6 cm)
Package 1 Width1.69 in (4.3 cm)
Package 1 Length2.09 in (5.3 cm)
Package 1 Weight1.52 oz (43 g)
Unit Type of Package 2S02
Number of Units in Package 240
Package 2 Height5.91 in (15 cm)
Package 2 Width11.81 in (30 cm)
Package 2 Length15.75 in (40 cm)
Package 2 Weight4.80 lb(US) (2.175 kg)

Main Document

Data Sheet : Download
